FEATURE

TECHNICAL SPECIFICATION

MODEL NUMBER

Dell Speakerphone with Multiport Adapter – MH3021P

DIMENSIONS (DIAMETER X HEIGHT)

119 mm x 32 mm (4.7 inch x 1.25 inch)

WEIGHT

214g (7.5 oz)

HOST CONNECTION

USB-C

CABLE TYPE; LENGTH

Round coaxial; 465 mm

USB-C CABLE (DATA /

POWER / VIDEO)

1 x USB-C multi functional cable that supports data transfer, power delivery and display/audio

TOTAL PORTS

1 x USB-C, 1 x HDMI, 2 x USB-A

DATA PORTS4

2 x USB-A 3.1 and 1 x USB-C 3.1 that supports data transfer up to 10Gbps

POWER DELIVERY

PORT3

1 x USB-C that supports power delivery up to 90W

VIDEO PORTS2

HDMI 2.0: 4K (3840 x 2160) @ 60Hz1 (HDR Support)

USB-C: 4K (3840 x 2160) @ 60Hz1 (HDR Support)

PLUG & PLAY

SUPPORT

Yes (No drivers installation)

SUPPORTED

OPERATING SYSTEM

Windows 10 64 Bit, Mac OS

SPEAKER TYPE

Electrodynamic Speaker with Neodymium Magnet

SPEAKER

FREQUENCY RANGE

200Hz – 20kHz

MICROPHONE

COVERAGE

360 degrees, omni-directional

MICROPHONE

FREQUENCY

100Hz – 10kHz

DIGITAL SIGNAL

PROCESSING

In-built echo cancellation and noise reduction

FEATURES

Answer an incoming call, End current call, Reject an incoming call,

Mute/Unmute, Volume +/-

SUPPORTED UC

PLATFORMS

Zoom certified and optimized for other leading UC platforms.

WHAT’S IN THE BOX

Dell Speakerphone with Multiport Adapter MH3021P, Pouch, Documentation

WARRANTY

1 year5

1 Available with select PC models (that support DisplayPort 1.4, HBR3) and when connected to displays that offer 4K resolution at 60Hz, with static HDR support. Dynamic HDR like HDR10/HDR10+/DolbyVision is excluded.

2 Only one video output is supported at a time. If the HDMI and USB-C video are connected at the same time, HDMI will have priority

3 Up to 90W can be used to charge your USB-C laptop. Actual power supplied is dependent on your power source/platform power policy

4 When the Dell Speakerphone with Multiport Adapter draws power from the laptop:

(a) and is connected to laptop’s USB-C/Thunderbolt port (3A/5V) – 2 downstream USB-A and 1 USB-C port support selected devices

(b) and is connected to laptop’s USB-C/Thunderbolt port (1.5A/5V) – 2 downstream USB-A ports and 1 USB-C can support low power consumption devices such as mouse, keyboard, Bluetooth / RF dongle, selected thumb drives

OR

When the Dell Speakerphone with Multiport Adapter is connected to USB-C power adapter or USB-C display:

and its USB-C cable is connected to laptop’s USB-C/Thunderbolt port – 2 downstream USB-A ports support selected devices
5 Pouch not covered.
Technical specifications subject to change without prior notice. Product availability varies by country. Please contact your Dell representative for more information.
