POLY CCX 400 MICROSOFT TEAMS EDITION

SPECIFICATIONS

USER INTERFACE FEATURES

• Gesture-based, multitouch-capable capacitive touch screen
• 5-inch color LCD (720 x 1280 pixel)
• 9:16 aspect ratio
• Screen saver
• On-screen virtual keyboard
• Voicemail support
• Adjustable base height
• One USB type-A port (2.0 compliant) for media and storage applications
• Unicode UTF-8 character support
• Adjustable font size selection (regular, medium, large)
• Normal and dark mode
• Multilingual user interface including Chinese, Danish, Dutch, English (Canada/ US/UK), French, German, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Slovenian, Spanish, and Swedish

AUDIO FEATURES

• Poly HD Voice technology delivers lifelike voice quality for each audio path; handset, hands-free speakerphone, and optional headset
• Poly Acoustic Clarity technology providing full-duplex conversations, acoustic echo cancellation and background noise suppression
• TIA-920 wideband audio, type 1 compliant (IEEE 1329 full duplex)
• Frequency response—150 Hz—7 kHz for handset, optional headset and handsfree speakerphone modes
• Codecs: G.711 (A-law and μ-law), G.729AB, G.722 (HD Voice), G.722.1 iLBC
• Individual volume settings with visual feedback for each audio path
• Voice activity detection
• Comfort noise generation
• DTMF tone generation (RFC 2833 and in-band)
• Low-delay audio packet transmission  Adaptive jitter buffers
• Packet loss concealment
• OPUS support

 HEADSET AND HANDSET COMPATIBILITY

•  Dedicated RJ-9 headset port
•  Hearing aid compatibility to ITU-T P.370 and TIA 504A standards
•  Compliant with ADA Section 508 Subpart B
•  1194.23 (all)
•  Hearing aid compatible (HAC) handset for magnetic coupling to hearing aids
•  Compatible with commercially-available TTY adapter equipment
•  USB headset support

NETWORK AND PROVISIONING

• SIP protocol support
• SDP
• IETF SIP (RFC 3261 and companion RFCs)
• Two-port gigabit Ethernet switch
• 10/100/1000Base-TX across LAN and PC ports
• Conforms to IEEE802.3-2005 (Clause 40) for Physical media attachment
• Conforms to IEEE802.3-2002 (Clause 28) for link partner auto-negotiation
• Manual or dynamic host configuration protocol (DHCP) network setup
• Time and date synchronization using SNTP
• FTP/TFTP/HTTP/HTTPS server-based central provisioning for mass deployments
• Provisioning and call server redundancy supported1
• QoS Support—IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS, and DHCP
• VLAN—CDP, DHCP VLAN discovery, LLDPMED for VLAN discovery
  • Network address translation support for static configuration and “keep-alive”
• SIP signaling
• RTCP and RTP support
• Event logging
• Syslog
• Hardware diagnostics
• Status and statistics reporting IPv4 and IPv6
• TCP
• UDP
• DNS-SRV

SECURITY

• 1X authentication and EAPOL Media encryption via SRTP
• Transport layer security (TLS) Encrypted configuration files
• Digest authentication
• Password login
• Support for URL syntax with password for boot server address
• HTTPS secure provisioning
  Support for signed software executables

POWER

• Built-in auto sensing IEEE 802.3af Power over Ethernet (Class 3) 13 W (Max)
• External Universal AC/DC Adapter (optional) 5 VDC @ 3 A (15 W)
• ENERGY STAR® rated

REGULATORY APPROVALS

• Australia RCM
• Brazil ANATEL
• Canada ICES and NRTLc
• EEA CE Mark
• Eurasian Customs Union EAC
• Indonesia SDPPI
• Japan VCCI
• Mexico NYCE
• NZ Telepermit
• Saudi Arabia CITC
• South Africa ICASA
• South Korea KC
• USA FCC and NRTL

SAFETY

• UL 62368-1
• CAN/CSA C22.2 No. 62368-1-14
• EN 62368-1
• IEC 60950-1 & IEC 62368-1
• AS/NZS 62368-1

EMC

• FCC Part 15 Class B
• ICES-003 Class B
• EN 55032 Class B
• EN 55024
• CISPR32 Class B
• VCCI Class B

OPERATING SYSTEM

• Android 9

OPERATING CONDITIONS

• Temperature: 0 to 40 °C (+32 to 104 °F)
• Relative humidity: 5% to 95%, noncondensing

STORAGE TEMPERATURE

• -40 to + 70 °C (-40 to + 160 °F)

POLY CCX 400 BUSINESS MEDIA PHONE COMES WITH:

• Console
• Handset with handset cord
• Network (LAN) cable—CAT-5E
• Desk Stand
• Setup Sheet

SIZE

• 18.1 cm x 21.5 cm x 5.0 cm WxHxD
• 7.1 in x 8.5 in x 2.0 in WxHxD

PART NUMBER

WEIGHT

• Unit weight: 1.043 kg (2.23 lbs)

MASTER CARTON QUANTITY

• Ten (10)

WARRANTY

• One (1) year

Nếu bạn cần thêm thông tin hãy kết nối với đội ngũ luôn sẵn sàng hỗ trợ bạn với liên hệ bên dưới!

CONNECT WITH SOUND ALLIANCE

Facebook     LinkedIn      YouTube      Twitter (X)

Hotline Tư vấn CSKH: +84 907 86 68 39

848Z8AA — Poly CCX 400 Business Media Phone for Microsoft Teams and PoE-enabled

848Z9AA — Poly CCX 400 Business Media Phone for Microsoft Teams and PoE-enabled GSA/TAA
