POLY EDGE B10 IP PHONE WITH POWER SUPPLY
CUỘC GỌI NÀO CŨNG TỰ TIN
Edge B10 có thiết kế tinh tế và chất lượng âm thanh vượt trội với mức giá hợp lý. Các phím bấm sáng dễ sử dụng, cấu hình plug-and-play, và độ tin cậy cao mang lại giá trị thực sự.
Âm Thanh Sắc Nét
Công nghệ Poly HD Voice và Poly Acoustic Fence đảm bảo chất lượng âm thanh doanh nghiệp, giảm tiếng ồn nền và giúp bạn nghe rõ mọi chi tiết của cuộc gọi.
Dễ Dàng Sử Dụng
Các phím chức năng sáng giúp bạn dễ dàng biết trạng thái tắt tiếng, loa ngoài hay tai nghe. Tính năng hội nghị âm thanh cục bộ 5 bên giúp bạn dễ dàng thêm đồng nghiệp vào cuộc gọi.
Quản Lý Hoàn Toàn Tự Động
Phần mềm quản lý trên nền tảng đám mây của Poly cho phép IT dễ dàng giám sát, quản lý và bảo trì thiết bị từ xa một cách an toàn với PDMS-SP và Poly Lens.
Phím LINE tiện dụng
Hiển thị 2 LINE và hỗ trợ gán phím 8 LINE với chức năng phân trang.
Tương Thích Tai Nghe
Hỗ trợ nhiều tùy chọn tai nghe Poly với cổng RJ9 và cổng tai nghe 3.5 mm.
Cài Đặt Đơn Giản
Thiết bị có hai cổng Ethernet 10/100 Base-TX 1 cho LAN và 1 cho máy tính. Tính năng cấu hình không chạm giúp điện thoại sẵn sàng sử dụng ngay từ khi mở hộp. Bộ chuyển đổi nguồn điện đi kèm (không hỗ trợ POE).
Gọi Điện Rảnh Tay
Loa ngoài với công nghệ loại bỏ tiếng vọng và giảm tiếng ồn nền giúp các cuộc gọi của bạn hiệu quả và đa năng hơn.
Có thể bạn đã biết HP đã sáp nhập Poly (Plantronics Inc) từ năm 2022. Sản phẩm Edge B10 sẽ có những biến thể với thông tin như bên dưới:
Model | Description | HP P/N | Poly P/N |
Edge B10 | Poly Edge B10 IP Phone with Power Supply-PRC | 84C19AA#AB2 | 2200-49800-022 |
Edge B10 | Poly Edge B10 IP Phone with Power Supply-US | 84C19AA#ABA | 2200-49800-001 |
Edge B10 | Poly Edge B10 IP Phone with Power Supply-EURO | 84C19AA#ABB | 2200-49800-101 |
Edge B10 | Poly Edge B10 IP Phone with Power Supply-AUST | 84C19AA#ABG | 2200-49800-012 |
Edge B10 | Poly Edge B10 IP Phone with Power Supply-JPN2 | 84C19AA#ABJ | 2200-49800-001 |
Edge B10 | Poly Edge B10 IP Phone with Power Supply-UK | 84C19AA#ABU | 2200-49800-102 |
POLY EDGE B10 IP PHONE WITH POWER SUPPLY
Specifications
Name |
Value |
OID |
2101750876 |
Product Number |
84C19AA |
Product Name |
Poly Edge B10 IP Phone with Power Supply PRC |
Product Line |
NI |
Application (facet) |
Google Workspace |
Audio Codecs |
G.711 (A-law and μ-law); G.722; G.729AB; iLBC; OPUS |
Audio Features |
Poly HD Voice; Full-duplex handsfree speakerphone with acoustic echo cancellation and background noise suppression; Individual volume settings with visual feedback for each audio path; Voice activity detection; Comfort noise generation; DTMF tone generation (RFC 2833 and in-band); Low delay audio packet transmission; Adaptive jitter buffers |
Brand (facet) |
Poly |
Cartons Per Layer |
6 |
Cartons Per Pallet |
36 |
Certifications and Compliances |
AS/NZS 60950-1; Australia RCM; Brazil ANATEL; CAN/CSA C22.2 No. 62368-1-14EN 60950-1; CE Mark; CISPR22 Class B; EN 60950-1 & EN 62368-1; EN55024; EN55032 Class B; EN61000-3-2, EN61000-3-3; FCC Part 15 (CFR 47) Class B; ICES-003 Class B; IEC 60950-1 & IEC 62368-1; NZ Telepermit; ROHS compliant; Saudi Arabia CITC; So. Africa ICASA; UAE TRA; UL 60950-1 and UL 62368-1; VCCI Class B; China RoHS 2; ENERGY STAR; Indonesia SDPPI; Mexico NOM ANCE; Russia CU |
Color |
Black |
Color (facet) |
Black |
Connectivity (facet) |
Audio |
Copyright Notice |
© Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. |
Country of Origin |
Made in China |
Datasheet Photo 01 |
https://ssl-product-images.www8-hp.com/digmedialib/prodimg/lowres/c08650402.png |
Datasheet Photo 02 |
https://ssl-product-images.www8-hp.com/digmedialib/prodimg/lowres/c08650502.png |
Datasheet Photo 03 |
https://ssl-product-images.www8-hp.com/digmedialib/prodimg/lowres/c08650466.png |
Display Size (diagonal) |
2.8" |
Display Size (diagonal, metric) |
7.1 cm (2.8") |
ECCN |
5A992 |
Energy Star Certified |
ENERGY STAR® certified |
External I/O Ports |
2 RJ-45 (10/100/1000BASE-TX Mbps) |
Features (facet) |
3.5 mm headset port |
HTS Code |
8517180020 |
Headset Ports |
1 RJ-9; 1 3.5 mm headset jack; 1 Electronic Hook Switch (EHS) with optional APD-80 adapter |
Headset and Handset Compatibility |
Compatible with commercially available TTY adapter equipment; Compliant with ADA Section 508 Subpart B 1194.23 (all); Hearing aid compatibility to ITU-TP.370 and TIA 504A standards; Hearing aid compatible (HAC) handset for magnetic coupling to hearing aids |
Management Software |
Poly Lens; Poly Zero Touch Provisioning; Polycom Device Management Service for Service Providers (PDMS-SP) Cloud Management; Web UI to device IP address |
Manufacturer Warranty |
Poly standard one-year limited warranty |
Multiple Order Quantity |
10 |
Operating Humidity Range |
5 to 95% |
Operating Temperature Range (celsius) |
0 to 40°C |
Operating Temperature Range (fahrenheit) |
32 to 104°F |
Package Dimensions (imperial) |
7.48 x 8.26 x 2.16 in |
Package Dimensions (metric) |
17.6 x 16.3 x 4.4 cm |
Package Weight (imperial) |
0.66 lb |
Package Weight (metric) |
1000 g |
Pallet (Layers) |
6 |
Pallet Dimensions (imperial) |
40.15 x 47.44 x 88.18 in |
Pallet Dimensions (metric) |
102 x 120.5 x 224 cm |
Pallet Weight (imperial) |
787.05 lb |
Pallet Weight (metric) |
357 kg |
Panel Technology |
Monochrome LCD |
Phone Type (facet) |
Physical dialpad; 2 line keys |
Power Features |
External AC/DC adapter 5VDC, 3A, 15 W |
Product Type (facet) |
Desk Phones |
Products Per Pallet |
360 |
Products per Pallet Layer |
60 |
Security Management |
802.1X Authentication and EAPOL Media encryption via SRTP; Digest authentication; HTTPS secure provisioning; Encrypted configuration files; Password login; Transport Layer Security (TLS); Support for signed software executables |
Segment (facet) |
Business |
Series Name (facet) |
Edge B10 |
Special Features |
Unicode UTF-8 character support; Adjustable desk stand (2 positions); Wall mountable |
Storage Temperature Range (celsius) |
-40 to 70°C |
Storage Temperature Range (fahrenheit) |
-40 to 158 °F |
Sub Brand (facet) |
Edge |
Supported Network Protocols |
Administrator password protected; DHCP VLAN discovery; LLDP-MED for VLAN discovery; FTP/TFTP/HTTP/HTTPS server-based central provisioning; Hardware diagnostics; Manual or dynamic host configuration protocol (DHCP) network setup; Network address translation support for static configuration and Keep-Alive; QoS Support — IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS, and DHCP; Status and statistics reporting; Syslog Event Logging; Conforms to IEEE802.3-2005 (Clause 40) for physical media attachment; Conforms to IEEE802.3-2002 (Clause 28) for link partner auto-negotiation; Time and date synchronization using SNTP; SIP signaling; RTCP and RTP support; IPv4; Provisioning and call server redundancy support; TCP; DNS-SRV; UDP |
Tech Spec Footnote 01 |
[1] Most software-enabled features must be supported by the service provider platform. Please contact your IP PBX/softswitch vendor or service provider for a list of supported features. |
Telephony and Call Handling Features |
4 context-sensitive soft keys; 4 way navigation key cluster with center Select key; 8 line keys (configurable, with pagination); Anonymous call indication; Background Firmware Updates (TR-69 support); Block anonymous call; Busy Lamp Field (BLF); Call forward on busy, on no answer, unconditional; Call logs (200); Call progress tone generation; Call return; Call timer and call waiting; Call transfer, hold, divert (forward), park, pickup; Caller ID enable/disable; Daylight savings time support — worldwide; Dialing from call logs; Distinctive incoming call treatment/call waiting; Distinctive ringtones; Do not disturb function; Electronic hook switch capable; Enhanced call park; Headset select key (illuminated when selected); Hold and transfer keys; Home and back feature keys; Local five-way audio conferencing; Message Waiting Indicator (MWI); One-touch speed dial, redial; Page Groups (10); Remote missed call notification; Repeat dialing; Shared call/bridged line appearance; Speed Dialing (99 entries, E.164 or URI); Call hold/resume, diversion (forward), transfer (consultation, blind), pickup; Calling, called, connected party identification; Call logs (missed, received, placed); 2 lines displayed; 2 line keys with LED |
UNSPSC Code |
43191511 |
UPC Number |
(ABA) 197497517149; (UUF) 197961922967 |
Usage (facet) |
Business |
User Type (facet) |
Everyday |
VoIP Features |
IETF SIP (RFC 3261 and companion RFCs); Up to 8 SIP line registrations with pagination key |
What Is In The Box |
Console; Desk stand/wall mount hardware; Handset with handset cord; Network (LAN) cable; Safety information sheet; Setup sheet with QR code to documentation and video; Power supply unit (PSU) |
Standard Part Number
Model |
Description |
HP P/N |
Poly P/N |
Edge B10 |
Poly Edge B10 IP Phone with Power Supply-PRC |
84C19AA |
2200-49800-022 |
Edge B10 |
Poly Edge B10 IP Phone with Power Supply-US |
84C19AA |
2200-49800-001 |
Edge B10 |
Poly Edge B10 IP Phone with Power Supply-EURO |
84C19AA |
2200-49800-101 |
Edge B10 |
Poly Edge B10 IP Phone with Power Supply-AUST |
84C19AA |
2200-49800-012 |
Edge B10 |
Poly Edge B10 IP Phone with Power Supply-JPN2 |
84C19AA |
2200-49800-001 |
Edge B10 |
Poly Edge B10 IP Phone with Power Supply-UK |
84C19AA |
2200-49800-102 |
Poly Edge B10 IP Phone with Power Supply
Category |
OID |
Product Number |
Status |
Recommended |
Product Name |
PRODUCT |
2101750876 |
84C19AA |
A |
Poly Edge B10 IP Phone with Power Supply PRC |
|
Services |
2101735178 |
P49800160 |
A |
1 Year Partner Poly+ Edge B10 IP Phone Service |
|
Services |
2101735525 |
P49800112 |
A |
1 Year Poly+ Edge B10 IP Phone Service |
|
Services |
2101735179 |
P49800362 |
A |
3 Year Partner Poly+ Edge B10 IP Phone Service |
|
Services |
2101735526 |
P49800312 |
A |
3 Year Poly+ Edge B10 IP Phone Service |
Properties | Value |
---|---|
OID |
2101750876 |
Product Number |
84C19AA |
Product Name |
Poly Edge B10 IP Phone with Power Supply |
data sheet | EN_US | Poly Edge B10 IP Phone with Power Supply |
Download |
