OID

2101802539

Product Number

89B59AA

Product Name

Poly OBi VVX 350 6-Line IP Phone and PoE-enabled

Product Line

NI

Application (facet)

Zoom (OpenSIP); Microsoft (OpenSIP gateway); RingCentral; OpenSIP

Audio Codecs

G.711 (A-law and μ-law); G.722; G.729AB; iLBC; OPUS

Audio Features

Poly HD Voice; Poly Acoustic Clarity technology provides full duplex conversations, acoustic echo cancellation, and background noise suppression; Poly Acoustic Fence technology eliminates background noise when using a handset or wired headset; Poly Computer Audio Connector app installed on your PC (Windows only) enables selecting your phone for PC audio in/out to use the phones handset, optional headset and handsfree speakerphone with PC applications; Individual volume settings with visual feedback for each audio path; Voice activity detection; Comfort noise generation; DTMF tone generation (RFC 2833 and in-band); Low delay audio packet transmission; Adaptive jitter buffers

Brand (facet)

Poly

Cartons Per Layer

6

Cartons Per Pallet

42

Certifications and Compliances

AS/NZS 60950-1; Australia RCM; Brazil ANATEL; CAN/CSA C22.2 No. 62368-1-14EN 60950-1; CE Mark; CISPR22 Class B; EN 60950-1 & EN 62368-1; EN55024; EN55032 Class B; EN61000-3-2, EN61000-3-3; FCC Part 15 (CFR 47) Class B; ICES-003 Class B; IEC 60950-1 & IEC 62368-1; NZ Telepermit; ROHS compliant; So. Korea KC; Saudi Arabia CITC; So. Africa ICASA; UAE TRA; UL 60950-1 and UL 62368-1; VCCI Class B; Indonesia SDPPI; Mexico NOM ANCE; Russia CU Mexico NOM ANCE;Russia CU;TAA

Color

Black

Color (facet)

Black

Connectivity (facet)

USB port; RJ-45; Power over Ethernet (PoE)

Copyright Notice

© Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Country of Origin

Made in China, Laos or Mexico

Datasheet Photo 01

https://ssl-product-images.www8-hp.com/digmedialib/prodimg/lowres/c08633296.png

Display Features

Digital picture frame

Display Size (diagonal)

3.5"

Display Size (diagonal, metric)

8.9 cm (3.5")

ECCN

5A992

Energy Star Certified

ENERGY STAR® certified

External I/O Ports

2 USB 2.0 Type-A (for media, storage applications, headset, optional Wi-Fi adapter); 2 RJ-45 (10/100/1000BASE-TX Mbps)

Features (facet)

Noise cancellation (NC); Supports optional Wi-Fi Adapter; USB headset support; Ethernet PC support

HTS Code

8517180020

Headset Ports

1 RJ-9; 1 Electronic Hook Switch (EHS) port for optional adapter

Headset and Handset Compatibility

Compatible with commercially available TTY adapter equipment; Compliant with ADA Section 508 Subpart B 1194.23 (all); Hearing aid compatibility to ITU-TP.370 and TIA 504A standards; Hearing aid compatible (HAC) handset for magnetic coupling to hearing aids

Management Software

Poly Lens; Poly Zero Touch Provisioning; Polycom Device Management Service for Service Providers (PDMS-SP) Cloud Management; SDP

Manufacturer Warranty

Poly standard one-year limited warranty

Multiple Order Quantity

10

Native Resolution

320 x 240

Operating Humidity Range

5 to 95%

Operating Temperature Range (celsius)

0 to 40°C

Operating Temperature Range (fahrenheit)

32 to 104°F

Package Dimensions (imperial)

7.48 x 8.26 x 2.16 in

Package Dimensions (metric)

23.3 x 26.2 x 6.2 cm

Package Weight (imperial)

0.66 lb

Package Weight (metric)

300 g

Pallet (Layers)

7

Pallet Dimensions (imperial)

40 x 48 x 58.66 in

Pallet Dimensions (metric)

101.6 x 121.9 x 149 cm

Pallet Weight (imperial)

787.05 lb

Pallet Weight (metric)

357 kg

Panel Technology

Color LCD

Phone Type (facet)

Physical dialpad; 6 line keys; Feature keys

Power Features

Built-in auto sensing IEEE 802.3af Power over Ethernet (Class 0); 13 W (maximum)

Power Features Footnote Number

[3]

Product Type (facet)

Desk Phones

Products Per Pallet

420

Products per Pallet Layer

60

Security Management

802.1X Authentication and EAPOL Media encryption via SRTP; Digest authentication; Encrypted configuration files; HTTPS secure provisioning; Password login; Support for signed software executables; Support for URL syntax with password; Transport Layer Security (TLS); SRTP media encryption using AES 256 bits

Segment (facet)

Business

Series Name (facet)

VVX IP 350

Special Features

Adjustable desk stand (2 positions); Unicode UTF-8 character support

Special Features Footnote Number

[2]

Storage Temperature Range (celsius)

-40 to 70°C

Storage Temperature Range (fahrenheit)

-40 to 158 °F

Sub Brand (facet)

VVX

Supported Network Protocols

10/100/1000 Base-TX across LAN and PC ports; Conforms to IEEE802.3-2005 (Clause 40) for physical media attachment; Conforms to IEEE802.3-2002 (Clause 28) for link partner auto-negotiation; Manual or dynamic host configuration protocol (DHCP) network setup

Tech Spec Footnote 01

[1] Most software-enabled features must be supported by the service provider platform. Please contact your IP PBX/softswitch vendor or service provider for a list of supported features.

Tech Spec Footnote 02

[2] Optional wall mount kit can be ordered separately.

Tech Spec Footnote 03

[3] External universal AC/DC adapter, 5 VDC, 3 A, 15 W (sold separately).

Telephony and Call Handling Features

Anonymous call indication; Block anonymous call; Busy Lamp Field (BLF); Call forward on busy, on no answer, unconditional; Call return; Distinctive incoming call treatment/call waiting; Do not disturb function; Repeat dialing; Shared call/bridged line appearance; Corporate directory; Call park/retrieve; Directed call pickup; Flexible line appearance (one or more line keys can be assigned for each line extension); Up to 6 SIP registrations per phone; Integrated IVR and Auto attendant; Up to 3-way locally mixed conference call; Call waiting; Maximum sessions control; External conference bridging; Visual voicemail support; XML Application Framework for third-party business and personal applications

Telephony and Call Handling Features Footnote Number

[1]

UNSPSC Code

43191511

Usage (facet)

Business

User Type (facet)

Everyday

VoIP Features

24 lines (SIP registrations)

What Is In The Box

Console; Desk stand/wall mount hardware; Handset with handset cord; Network (LAN) cable-CAT-5E; Setup sheet
